Contact Vinidex Customer Service for availability of products on this page.
EasyLOK Metric Tees PE x PE x FI BSP
| Vinidex Code | Philmac Code | Nominal Size (mm x mm x inch) | Min. (Bag) Quantity | Carton Quantity |
| 95203 | 97893100 | 25 x ½ | 10 | 120 |
| 95204 | 97893200 | 25 x ¾ | 10 | 120 |
| 95219 | 97642100 | 20 x 20 x ½ | 10 | 120 |
| 95220 | 97642200 | 20 x 20 x ¾ | 10 | 120 |
| 95221 | 97643100 | 25 x 25 x ½ | 10 | 80 |
| 94077 | 97643200 | 25 x 25 x ¾ | 10 | 70 |
| 94078 | 97643300 | 25 x 25 x 1 | 10 | 70 |
| 95222 | 97644200 | 32 x 32 x ¾ | 5 | 45 |
| 95223 | 97644300 | 32 x 32 x 1 | 5 | 45 |
| 94079 | 97644400 | 32 x 32 x 1¼ | 5 | 40 |
| 95224 | 97645300 | 40 x 40 x 1 | 1 | 25 |
| 95225 | 97645400 | 40 x 40 x 1¼ | 1 | 25 |
| 94080 | 97645500 | 40 x 40 x 1½ | 1 | 23 |
| 95112 | 97646500 | 50 x 50 x 1½ | 1 | 18 |
| 95113 | 97646600 | 50 x 50 x 2" | 1 | 15 |
| 95114 | 97647400 | 63 x 63 x 1¼ | 1 | 9 |
| 95115 | 97647500 | 63 x 63 x 1½ | 1 | 9 |
| 95072 | 97647600 | 63 x 63 x 2 | 1 | 9 |
| 95065 | 97648600 | 75 x 75 x 2 | 1 | 8 |
| 95116 | 97648700 | 75 x 75 x 2½ | 1 | 8 |
| 95117 | 97648800 | 75 x 75 x 3 | 1 | 8 |
| 95070 | 97649800 | 90 x 90 x 3 | 1 | 4 |
| 95111 | 97640900 | 110 x 110 x 4 | 1 | 3 |
